CT-C Hot Air banana fuit tray dryer drying machine oven is initiated by our company and reaches the international level after several updates. This hot air banana fruit tray dryer drying machine overcomes the disadvantages of long drying time, great heat loss. CT hot air banana fruit tray dryer drying machine uses the steam heater or electrical heating organ to create heat and change heat through convective wind to heat up the material.
Products Details
1.DESCRIPTION of CT hot air banana fruit tray dryer drying machine
CT-C Hot Air banana fuit tray dryer drying machine oven is initiated by our company and reaches the international level after several updates. This hot air banana fruit tray dryer drying machine overcomes the disadvantages of long drying time, great heat loss. CT hot air banana fruit tray dryer drying machine uses the steam heater or electrical heating organ to create heat and change heat through convective wind to heat up the material.
Meanwhile it renews fresh air and expels wet air. The heat wind can cycle in the oven, so it saves the source. The hot air banana fruit tray dryer drying machine oven can be used to heating and expel wet air in pharmaceutical industry, chemical industry, foodstuff industry, light industry, heavy industry, etc.
2.MAIN APPLICATION of CT hot air banana fruit tray dryer drying machine
For pharmaceutical, chemical, food, agricultural and sideline products, water products, light industry, heavy industry and other industries of the heating and curing, drying and dehydration. Such as raw materials, raw materials, Chinese herbal medicine, extract, powder, granules, powder, pills, water bottles, pigment, dyestuff, dehydration vegetable, dried fruit and melons, sausage, plastic resin, electric elements, paint etc
CT hot air banana fruit tray dryer drying machine can used as industrial fruit and food dehydrator dehydrating machine. for drying fruits and vegetables, mushroom, chili, spice, turmeric, herbal material etc
3.TECHNICAL PARAMETERS of CT hot air banana fruit tray dryer drying machine
Note: we also can design other model upon client's request.
Model | Evaporated area(m²) | Effective volume((m³) | Capacity(kg/batch) | Radiator Area(m²) | Steam (kg/h) | Electric Power (kw) | FanVolume (m³/h) | Fan Power (kw) | Inner Temp. Difference(℃) | Overall(mm) | CarNo. | TrayNo. | Weight(kg) |
CT-C-0 | 7.1 | 1.3 | 60 | 15 | 15 | 6-9 | 4510 | 0.45 | ±1 | 1380×1200×2000 | 1 | 24 | 820 |
CT-C-Ⅰ | 14.1 | 2.6 | 120 | 23 | 20 | 15 | 4510 | 0.45 | ±2 | 2360×1200×2000 | 2 | 48 | 1580 |
CT-C-Ⅱ | 28.3 | 4.9 | 240 | 48 | 40 | 30 | 9020 | 0.45 ×2 | ±2 | 2260×2200×2000 | 4 | 96 | 1800 |
CT-C-Ⅲ | 42.4 | 7.4 | 360 | 72 | 60 | 45 | 13530 | 0.45×3 | ±2 | 3240 ×2200 ×2000 | 6 | 144 | 2210 |
CT-C-IV | 56.5 | 10.3 | 500 | 96 | 80 | 60 | 18040 | 0.45×4 | ±2 | 4280 ×2200×2770 | 8 | 192 | 2800 |
