Features and Applications of Cut-and-grind Machine

The cutting and crushing machine is suitable for soft, brittle, medium-hard and fibrous samples, and provides gentle and rapid preparation of samples in a short time, and can be used for freezing and grinding of heat-sensitive samples. A large number of optional accessories make it a versatile instrument widely used in various fields.

CSJ Horizontal Arabic Gum Turmeric Ginger Cumin Powder crusher

Working Principle

The sample enters through the inlet of the high-speed cutting and grinding machine and first falls through a funnel that prevents back splashing onto the rotating rotary knife. Due to the centrifugal acceleration, the sample makes an outward motion toward the knife wing. It has a very high rotational speed, the impact between the two produces a cutting and crushing effect, and the secondary shear and friction between the rotating knife and the ring sieve, the sample size is smaller than the ring sieve aperture, after entering the circle-shaped collection plate.

With this two-stage crushing method, the sample preparation process is gentle and fast, and the sample remains in the crushing chamber only for a short time, and the sample properties are not changed by the sample preparation process.

Technical features

Fast two-stage pulverization, coarse and fine pulverization in one step

Dry grinding, freezing grinding are available

Anti-splash inlet, safety switch and mechanical lock, double to ensure the safety of laboratory personnel

A variety of materials and specifications of accessories available to ensure the application of diversification

Rotational speed can be set, easy to operate

Instrument with anti-overload function

The instrument can be equipped with automatic sample filler and cyclone separator, which can carry out a large number of sample preparation

WF Arabic Gum guar tea leaf matcha Grinder for sale

Product applications

Pharmaceutical materials, chemicals, coffee beans, rice, dried fruits and vegetables, waste materials, wood, plant materials, tobacco, corn, seeds, straw, paper, fertilizers, collagen, pharmaceuticals, cereals, spices, etc.

For temperature-sensitive samples, the extremely fast rotating knife ensures high grinding speeds. The thermal effect on the ground sample is completely reduced.

It can also be used for samples that are difficult to grind, for example, by adding liquid nitrogen to embrittle them before grinding, thus achieving analytical grade fineness and grinding results.

WANTONG also has cryogenic pulverizers for sale. Low-temperature crusher system with liquid nitrogen as the source of cold, crushed materials through cooling at low temperatures to achieve brittle easy to crush state, into the mechanical crusher cavity through the impeller speed rotation, the material and blade, tooth plate, material and material between the repeated impact, collision, shear, friction and other comprehensive effect, to achieve the crushing effect: the crushed material has a gas sieve machine line separation and collection: the material does not reach the fineness requirements Return to the silo to continue to crush, most of the cold air back to the silo recycling.

If you need to buy, please contact us. WANTONG is committed to the research and development of food ingredients crusher, we provide serious service.
