This v mixer for spice is applicable to mix dry powder and granule material for the pharmacy and other relative industries.v shaped mixer machine can mixing dry small food, industrial, pharmaceutical powder very evenly. like tea,matcha, sugar, additives supplement,potein powder etc .
Products Details
1. CHARACTERISTICS of v shaped mixer for spice
This v mixer for spice is easy to operate and v blender mixes evenly with the vacuum charging equipment. v mixer can also be equipped with compulsive blending setup. v mixer can mix fine powder and more than two forms of powders including the materials that contain water. can get the good result of mixing little quantity materials and additive (meaning that little admixture additives). Adopted unbalance canister body.
2. MAIN FEATURE of v shaped mixer for spice
1. this v mixer is made up of stainless steel 304(we also can do as consumer requirement)
2. this v mixer has a total volume 0.18 m^3 empty
3. this v mixer is meeting ISO 9001 and CE and GSG certificate
4. this v mixer is suitable for mix powder, granule
5. this v mixer can add the stir bar inside mix tank, it also can add the spray system to spray liquid (if consumer need. inform us in advance)
6. this v mixer can make into vacuum condition (if consumer need, inform us in advance)
7. this v mixer can add the frequency changer (adjust the rotation speed), if consumer need, inform us in advance
8. voltage: 220v or 380v or as consumer requirement
3. TECHNICAL PARAMETERS of v shaped mixer for spice
| Type | V-200 | V-300 | V-500 | V-1000 | V-2000 | V-3000 | V-4000 | ||
| Barrel Volume(m3) | 0.2 | 0.3 | 0.5 | 1.0 | 2.0 | 3 | 4 | ||
| Capacity(kg/batch) | 40 | 60 | 100 | 200 | 400 | 600 | 800 | ||
| Mixing time(min) | 3-8 | 6-10 | |||||||
| Blending speed(r/min) | 12 | 12 | 12 | 10 | 10 | 8 | 8 | ||
| Power（KW） | 1.1 | 1.1 | 2.2 | 4 | 7.5 | 11 | 15 | ||
| Overall Size（L*W*H）(mm) | 2000*400*1600 | 2050*710*1700 | 2370*1000*1850 | 2900*1350*2450 | 3340*1650*2980 | 4690*2200*4000 | 4950*2200*4230 | ||
| Weight(kg) | 290 | 300 | 550 | 850 | 2040 | 2500 | 2800 | ||
