The cryogenic grinder for rubber can be widely used for material crushing in pharmaceutical, food, chemical industry, national defense , scientific research and other industries.
For heat sensitive substances, Chinese and Western medicine, tissues of animals and plants, rubber, plastic and other materials which are tough and can not be crushed at room temperature.
The rubber cold milling machine is a cryogenic grinder of derivative products, compared to the small size, low loss, low energy consumption, simple operation, is China's first set of productivity and energy efficiency in one of the mill. Widely used in the food industry, the pharmaceutical industry and test polymer materials
Products Details
Application:
The rubber cold milling machine is a cryogenic grinder of derivative products, compared to the small size, low loss, low energy consumption, simple operation, is China's first set of productivity and energy efficiency in one of the mill. Widely used in the food industry, the pharmaceutical industry and test polymer materials and the like.
Working Principle
Cryogenic comminution is that the materials which are metioned above are frozen to a brittle temperature, then it is crushed into the required fineness in the crusher, and the original composition will not be destroyed. In addition, flammable and explosive materials at room temperature can also be crushed at low temperature by this machinery which is of high efficiency.
The liquid nitrogen cryogenic mill systems for the cold source, after being crushed material crushed by cooling to achieve brittle state at a low temperature, into the cavity through the high-speed rotating machinery grinder impeller, materials and blades, tooth plate, materials and materials of repeated impact between each other, under the impact, shear and friction, combined effects, to the crushing effect; the material is crushed airflow screening machine grading and collected does not reach the required fineness of the material to return silos continue crushing, large air-conditioning partial returns recycling bin.
TECHNOLOGY DATA
| Spec. & Model | 200 | 550 | 800 | |
| Crusher chamber diameter (mm) | 200 | 550 | 800 | |
| Production capacity(kg/h) | 20-100 | 300-500 | 400-1000 | |
| Input size | ≤2cm | |||
| Fine crushed size(mesh) | 10-700(adjustable, upon material ) | |||
| Crusher power(kw) | 7.5 | 45 | 85 | |
| Feed power(kw) | 0.37 | 3 | 4 | |
| Medium | Liquid nitrogen | |||
| Temperature ℃ | -196~ 0 | |||
The above specifications are provided for reference only. We can also design and manufacture different standard upon customer‘s request.
