This YK swing granulator for fodder is widely used in pharmaceutical industry, chemical industry, foodstuff industry, powdered drink and so on. It can make wet powder material particles, can also be used to crush the blocked raw material into small granule quickly.
Products Details
1.MAIN USE of YK Swing Granulator For Fodder
This YK granulator for fodder is a kind of wet powder mixture in a rotating drum, the counter rotating under the action of special equipment made mandatory through the sieve particles.
2.TECHNICAL PARAMETERS of YK Swing Granulator For Fodder
| TYPE | YK-100 | YK-120 | YK-160 | YK-200 |
| CAPACITY(kg/h) | 30-100 | 50-200 | 100-300 | 200-500 |
| POWER(kw) | 1.1 | 1.5 | 2.2 | 5.5 |
| ROTATING BARREL SPEED (r/min) | 55 | 55 | 55 | 55 |
| SWAY ANGLE | 360° | |||
| ROTATING BARREL DIAMETER (mm) | Ф100 | Ф120 | Ф160 | Ф200 |
| OVERALL SIZE（L×W×H） | 600X300X980 | 800X500X1100 | 1000×800×1300 | 1270×1000×1400 |
| WEIGHT (kg) | 180 | 260 | 350 | 500 |
